5V power supply and the rated current is 300 μA. It works on half-duplex communication to implement the function of converting the TTL level into RS-485 level which means it can either transmit or receive at any time, not both, it can achieve a maximum transmission rate of 2.5Mbps. MAX485 transceiver draws a supply current of between 120μA and 500μA under the unloaded or fully loaded conditions when the driver is disabled. The driver is limited for short-circuit current and the driver outputs can be placed at a high impedance state through the thermal shutdown circuit. It also has onboard LEDs to display the current state of the chip i.e. whether the chip is powered or its transmitting or receiving data making it easier to debug and use. Slave devices use the master in/slave out pin, MISO, for transmitting, and the master out/slave in pin, MOSI, for receiving data. The equipment located along a set of RS-485 wires are interchangeably called nodes, stations or devices. It may be used to control video surveillance systems or to interconnect security control panels and devices such as access control card readers. There are several protocols that govern the format of exchanged data, with the RS232 protocol used primarily by personal computers, and the RS485 protocol used in industrial control systems.

Single master systems (many other communications schemes are available) offer a straight forward and simple means of avoiding "data collisions" in a typical 2-wire, half-duplex, multi-drop system. This method is one of the simple and easy to implement methods to transfer the data over long distances. An example of how a byte(0x3E) is transferred over the two lines of RS485 Communication. The connection between two or more elements (drivers and receivers) should be considered a transmission line if the rise and/or fall time is less than half the time for the signal to travel from the transmitter to the receiver. Since it uses a differential line over twisted pair (like EIA-422), rs485 cable it can span relatively large distances (up to 4000 feet or just over 1200 metres). We will send some data from the transmitter side over the cable from the Nano which is converted to RS485 signals via MAX RS485 Module working in Master Mode. Differential signals can help nullify the effects of ground shifts and induced noise signals that can appear as common mode voltages on a network. Noise in the range of ±200 mV is essentially blocked due to common-mode noise cancellation. The main reason behind using these Ethernet Cables over normal wires is that they provide much better protection against noise creeping in and distortion of the signal over high distances.

Because differential signals have inherently better signal-to-noise properties, reliable RS422 communications can be sent over much longer distances compared to RS232. So, in the Arduino code, we will focus on sending the data and display that sent or received data on the LCD screen. We start with including the standard library for driving the LCD and declare the D8 pin of the Arduino Nano as an output pin which we will later use to declare the MAX485 Module as a transmitter or Receiver. Here again, we start with including the standard library for driving the LCD and declare the D8 pin of the Arduino Nano as an output pin which we will later use to declare the MAX485 Module as a transmitter or Receiver. We will also initialize the LCD here and print a welcome message. First, we will go over the Gen 2 and Gen 3 modules, because they are more common. Standards have been developed to insure compatibility between units provided by different manufacturers, and to allow for reasonable success in transferring data over specified distances and/or data rates. Any number of characters can be sent, and the transmitter will automatically re-trigger with each new character (or in many cases a "bit-oriented" timing scheme is used in conjunction with network biasing for fully automatic operation, including any Baud rate and/or any communications specification, eg.

Both the local and remote UARTs must be configured for the same baud rate. In this project, we have only used a baud rate of 9600 which is well under the maximum transfer speed we can achieve with the MAX-485 Module but this speed is suitable for most of the sensor modules out there and we don’t really need all the maximum speeds while working with Arduino and other development boards unless you are using the cable as an ethernet connection and require all the bandwidth and transfer speed you can get. The advantage of using Serial1 for RS485 is that the Serial1 RS485 signals are also available on the Docking Panel, while the Serial2 RS485 signals are available only on the PDQ Board’s Serial Communications Header. A write collision occurs when a byte is written to the SPI data register, SPDR, while data is being exchanged. Ideally, the two ends of the cable will have a termination resistor connected across the two wires and two powered resistors to bias the lines apart when the lines are not being driven. Serial 2 is implemented by a software UART in the controller’s QED-Forth Kernel that uses two of the processor’s PortA I/O pins to generate a serial communications channel.
